Service Boundaries and Domain-Driven Design in .NET Core and Azure

This article is part of the Comprehensive Guide to Microservices Architecture in .NET Core, Cloud and Azure series.

What “Explicit Context Mapping” means (in DDD terms)

In DDD, context mapping is how you define and document the relationships between bounded contexts (separate domain models owned by different teams or services). Making it explicit means you don’t let integration “just happen” through ad-hoc calls or shared tables—you codify the relationships, the integration style (e.g., Customer-Supplier, Shared Kernel, Open Host Service), and the translation layer between models so it’s visible in code and contracts, not tribal knowledge. (martinfowler.com)

How to do it in .NET (Core) — a minimal, workable recipe

Carve out bounded contexts

Split into separate projects (or services) with their own models, persistence, and language.

/src
  /SalesContext.Api
  /SalesContext.Domain
  /SalesContext.Infrastructure (EF Core, Migrations)
  /BillingContext.Api
  /BillingContext.Domain
  /BillingContext.Infrastructure
  /Contracts (versioned DTOs/events)

Document the relationship (e.g., Sales is upstream, Billing is downstream using Customer-Supplier with Published Language via events/HTTP). (ddd-crew on GitHub)

Choose an integration style and make it concrete

Common explicit patterns:

Open Host Service + Published Language (HTTP/REST or gRPC with explicit contracts)
Event Publication (messages with versioned schemas)
Anti-Corruption Layer (ACL) (an adapter/translator that shields your domain from upstream models)

Pick one per interaction and stick it in code (see next steps). (InfoQ)

Define explicit contracts (don’t leak domain models)

Create a Contracts assembly shared only as schemas (not domain types).

// Contracts/Orders/v1/OrderPlaced.v1.cs
namespace Contracts.Orders.V1;
public record OrderPlacedV1(
    Guid OrderId,
    Guid CustomerId,
    decimal TotalAmount,
    string Currency,
    DateTimeOffset OccurredAt);

Version contracts (V1, V2…) and keep them stable.

Build an Anti-Corruption Layer in the downstream context

Put all mapping code in one place so domain stays pure.

// BillingContext.Infrastructure/Integration/OrdersAcl.cs
using Contracts.Orders.V1;
using BillingContext.Domain.Billing;

public interface IOrdersAcl {
    InvoiceDraft Translate(OrderPlacedV1 evt);
}

public sealed class OrdersAcl : IOrdersAcl {
    public InvoiceDraft Translate(OrderPlacedV1 evt) =>
        InvoiceDraft.Create(
            invoiceId: Guid.NewGuid(),
            orderId: evt.OrderId,
            customerId: evt.CustomerId,
            amount: Money.Of(evt.TotalAmount, evt.Currency),
            issuedAt: evt.OccurredAt);
}

You can hand-roll mappings (fast/explicit), or use a mapper (AutoMapper/Mapster/TransverseMapper) if you prefer. Mapster supports code-gen for explicit mapper classes if you want compile-time safety. (GitHub)

Wire it through messaging or HTTP

Example: event consuming (MassTransit/NServiceBus/ReBus or raw Rabbit/Kafka). Here’s a handler calling the ACL:

// BillingContext.Api/Consumers/OrderPlacedConsumer.cs
using Contracts.Orders.V1;
using MassTransit;

public class OrderPlacedConsumer : IConsumer<OrderPlacedV1> {
    private readonly IOrdersAcl _acl;
    private readonly IBillingRepository _repo;

    public OrderPlacedConsumer(IOrdersAcl acl, IBillingRepository repo) {
        _acl = acl; _repo = repo;
    }

    public async Task Consume(ConsumeContext<OrderPlacedV1> context) {
        var draft = _acl.Translate(context.Message);
        await _repo.SaveDraftAsync(draft, context.CancellationToken);
    }
}

For Open Host Service: expose a minimal API in Sales with DTOs from Contracts, consume in Billing, then pass through the ACL.

Keep persistence mapping internal to each context

Use EF Core configurations inside each context; never expose these types across contexts.

// BillingContext.Infrastructure/Config/InvoiceConfig.cs
using Microsoft.EntityFrameworkCore;
using Microsoft.EntityFrameworkCore.Metadata.Builders;

internal sealed class InvoiceConfig : IEntityTypeConfiguration<Invoice> {
    public void Configure(EntityTypeBuilder<Invoice> b) {
        b.ToTable("Invoices");
        b.HasKey(i => i.Id);
        b.OwnsOne(i => i.Amount, m => {
            m.Property(p => p.Value).HasColumnName("Amount");
            m.Property(p => p.Currency).HasColumnName("Currency").HasMaxLength(3);
        });
        b.Property(i => i.IssuedAt);
        // etc.
    }
}

(These are regular EF Core mappings—separate from context mapping—but important to keep bounded context persistence clean.) ([Anton Dev Tips][5])

Test the map (contract tests)

Consumer tests in Billing verify that a recorded OrderPlacedV1 yields the expected InvoiceDraft.
Provider tests in Sales verify it emits OrderPlacedV1 matching schema. This locks the integration map and catches breaking changes early.

Tiny, end-to-end example (HTTP, Open Host + ACL)

Sales exposes an endpoint with a published language:

// SalesContext.Api/OrdersController.cs
[ApiController]
[Route("api/orders")]
public class OrdersController : ControllerBase {
    [HttpGet("{id:guid}")]
    public ActionResult<Contracts.Orders.V1.OrderDtoV1> Get(Guid id) {
        var order = _app.GetOrder(id);
        return new Contracts.Orders.V1.OrderDtoV1(
            order.Id, order.CustomerId, order.Total.Value, order.Total.Currency);
    }
}

Billing calls it and uses the ACL:

// BillingContext.Infrastructure/Integration/OrdersClient.cs
public sealed class OrdersClient(HttpClient http) {
    public async Task<OrderDtoV1?> Get(Guid id, CancellationToken ct) =>
        await http.GetFromJsonAsync<OrderDtoV1>($"api/orders/{id}", ct);
}

// BillingContext.Application/UseCases/GenerateInvoice.cs
public sealed class GenerateInvoice {
    private readonly OrdersClient _client;
    private readonly IOrdersAcl _acl;
    private readonly IBillingRepository _repo;

    public async Task Handle(Guid orderId, CancellationToken ct) {
        var dto = await _client.Get(orderId, ct) ?? throw new InvalidOperationException();
        var draft = _acl.Translate(new OrderPlacedV1(dto.OrderId, dto.CustomerId, dto.Total, dto.Currency, DateTimeOffset.UtcNow));
        await _repo.SaveDraftAsync(draft, ct);
    }
}

The map is explicit: contracts, translation, and the chosen relationship are all visible in code and docs.

Tips & pitfalls

Never reference another context’s domain types—only contracts.
Put all cross-context translations in one ACL layer, not scattered.
Version contracts (V1/V2) and don’t break old consumers.
Prefer domain language inside each context; translations happen only at the edges.
Document the chosen patterns (Customer-Supplier, Shared Kernel, etc.) in your repo’s /architecture/ folder.

Tools for Bounded Context Definition:

Context Mapper: A DSL for strategic DDD
EventStorming: Workshop-based approach to identify boundaries
C4 Model diagrams: Visual documentation of contexts
.NET Aspire: For local development orchestration of bounded contexts

Example with .NET Aspire:

// AppHost/Program.cs
var builder = DistributedApplication.CreateBuilder(args);

var orderService = builder.AddProject<Projects.OrderService>("order-service");
var customerService = builder.AddProject<Projects.CustomerService>("customer-service");
var inventoryService = builder.AddProject<Projects.InventoryService>("inventory-service");

builder.Build().Run();

Analyzing Coupling

Coupling Analysis Techniques:

Static Code Analysis using NDepend or Roslyn Analyzers:

// Custom Roslyn Analyzer to detect cross-boundary references
[DiagnosticAnalyzer(LanguageNames.CSharp)]
public class BoundedContextAnalyzer : DiagnosticAnalyzer
{
    public override void Initialize(AnalysisContext context)
    {
        context.RegisterSyntaxNodeAction(AnalyzeNode,
            SyntaxKind.UsingDirective);
    }

    private void AnalyzeNode(SyntaxNodeAnalysisContext context)
    {
        // Check for references across bounded contexts
    }
}

Dependency Graphs - Use Visual Studio or Rider's architecture tools
ArchUnit.NET for architectural testing:

[Test]
public void OrderService_Should_Not_Reference_CustomerService()
{
    var architecture = new ArchLoader()
        .LoadAssemblies(typeof(OrderService).Assembly)
        .Build();

    var rule = Types()
        .That().ResideInNamespace("OrderManagement")
        .Should().NotDependOnAny("CustomerManagement.Domain");

    rule.Check(architecture);
}

Analyzing Communication

Tools and Approaches:

Application Insights with dependency tracking:

services.AddApplicationInsightsTelemetry(options =>
{
    options.ConnectionString = configuration["ApplicationInsights:ConnectionString"];
    options.EnableDependencyTrackingTelemetryModule = true;
});

Distributed Tracing with OpenTelemetry:

services.AddOpenTelemetry()
    .WithTracing(tracerProviderBuilder =>
    {
        tracerProviderBuilder
            .AddAspNetCoreInstrumentation()
            .AddHttpClientInstrumentation()
            .AddAzureMonitorTraceExporter();
    });

Service Mesh (like Dapr or Linkerd) provides communication analytics out-of-the-box.
