Security Best Practices in .NET Core and Azure

This article is part of the Comprehensive Guide to Microservices Architecture in .NET Core, Cloud and Azure series.

This article explores essential security patterns and best practices for .NET applications, with a focus on Azure integration and modern authentication protocols.

Authentication and Authorization

Proper authentication verifies user identity, while authorization ensures users can only access resources they're permitted to use.

JWT Bearer Authentication

JSON Web Tokens (JWT) provide a stateless authentication mechanism ideal for distributed systems:

// Configure JWT authentication in Program.cs
builder.Services.AddAuthentication(JwtBearerDefaults.AuthenticationScheme)
    .AddJwtBearer(options =>
    {
        options.Authority = builder.Configuration["Auth:Authority"];
        options.Audience = builder.Configuration["Auth:Audience"];
        options.MetadataAddress = builder.Configuration["Auth:MetadataAddress"];

        options.TokenValidationParameters = new TokenValidationParameters
        {
            ValidateIssuer = true,
            ValidateAudience = true,
            ValidateLifetime = true,
            ValidateIssuerSigningKey = true,
            ClockSkew = TimeSpan.Zero, // No tolerance for expired tokens
            NameClaimType = "name",
            RoleClaimType = "roles"
        };

        options.Events = new JwtBearerEvents
        {
            OnAuthenticationFailed = context =>
            {
                if (context.Exception is SecurityTokenExpiredException)
                {
                    context.Response.Headers.Append("Token-Expired", "true");
                }

                context.Response.Headers.Append("Token-Error",
                    context.Exception.Message);

                return Task.CompletedTask;
            },

            OnTokenValidated = context =>
            {
                // Additional validation logic
                var userId = context.Principal?.FindFirst("sub")?.Value;
                // Log successful authentication, check revocation list, etc.
                return Task.CompletedTask;
            },

            OnChallenge = context =>
            {
                // Custom challenge handling
                context.HandleResponse();
                context.Response.StatusCode = StatusCodes.Status401Unauthorized;
                context.Response.ContentType = "application/json";

                var result = JsonSerializer.Serialize(new
                {
                    error = "unauthorized",
                    error_description = context.ErrorDescription
                });

                return context.Response.WriteAsync(result);
            }
        };

        // For development only - disable HTTPS requirement
        if (builder.Environment.IsDevelopment())
        {
            options.RequireHttpsMetadata = false;
        }
    });

var app = builder.Build();

// Enable authentication and authorization middleware
app.UseAuthentication();
app.UseAuthorization();

Authorization Policies

Define fine-grained authorization policies for different access levels:

builder.Services.AddAuthorization(options =>
{
    // Role-based policy
    options.AddPolicy("AdminOnly", policy =>
        policy.RequireRole("Admin", "SuperAdmin"));

    // Claims-based policy
    options.AddPolicy("CanViewOrders", policy =>
        policy.RequireClaim("permissions", "orders:read"));

    options.AddPolicy("CanManageOrders", policy =>
        policy.RequireClaim("permissions", "orders:write", "orders:delete"));

    // Custom requirement policy
    options.AddPolicy("CanCreateOrders", policy =>
        policy.Requirements.Add(new MinimumAgeRequirement(18)));

    // Combined requirements
    options.AddPolicy("SeniorAdmin", policy =>
    {
        policy.RequireRole("Admin");
        policy.RequireClaim("seniority", "senior");
        policy.Requirements.Add(new MinimumAgeRequirement(25));
    });

    // Default policy for all authorized endpoints
    options.FallbackPolicy = new AuthorizationPolicyBuilder()
        .RequireAuthenticatedUser()
        .Build();
});

Custom Authorization Handlers

Implement custom authorization logic for complex business rules:

// Custom requirement
public class MinimumAgeRequirement : IAuthorizationRequirement
{
    public int MinimumAge { get; }

    public MinimumAgeRequirement(int minimumAge)
    {
        MinimumAge = minimumAge;
    }
}

// Handler for the requirement
public class MinimumAgeHandler : AuthorizationHandler<MinimumAgeRequirement>
{
    private readonly ILogger<MinimumAgeHandler> _logger;

    public MinimumAgeHandler(ILogger<MinimumAgeHandler> logger)
    {
        _logger = logger;
    }

    protected override Task HandleRequirementAsync(
        AuthorizationHandlerContext context,
        MinimumAgeRequirement requirement)
    {
        var dateOfBirthClaim = context.User.FindFirst(c =>
            c.Type == "date_of_birth" || c.Type == "birthdate");

        if (dateOfBirthClaim == null)
        {
            _logger.LogWarning("Date of birth claim not found for user");
            return Task.CompletedTask;
        }

        if (DateTime.TryParse(dateOfBirthClaim.Value, out var dateOfBirth))
        {
            var age = DateTime.Today.Year - dateOfBirth.Year;
            if (dateOfBirth.Date > DateTime.Today.AddYears(-age))
            {
                age--;
            }

            if (age >= requirement.MinimumAge)
            {
                _logger.LogDebug(
                    "User age {Age} meets minimum requirement {MinAge}",
                    age, requirement.MinimumAge);
                context.Succeed(requirement);
            }
            else
            {
                _logger.LogWarning(
                    "User age {Age} does not meet minimum requirement {MinAge}",
                    age, requirement.MinimumAge);
            }
        }

        return Task.CompletedTask;
    }
}

// Resource-based authorization
public class OrderAuthorizationHandler :
    AuthorizationHandler<OperationAuthorizationRequirement, Order>
{
    protected override Task HandleRequirementAsync(
        AuthorizationHandlerContext context,
        OperationAuthorizationRequirement requirement,
        Order resource)
    {
        var userId = context.User.FindFirst("sub")?.Value;

        if (requirement.Name == "Edit" || requirement.Name == "Delete")
        {
            // Only order owner or admin can edit/delete
            if (resource.CustomerId.ToString() == userId ||
                context.User.IsInRole("Admin"))
            {
                context.Succeed(requirement);
            }
        }
        else if (requirement.Name == "View")
        {
            // Order owner, admin, or support can view
            if (resource.CustomerId.ToString() == userId ||
                context.User.IsInRole("Admin") ||
                context.User.IsInRole("Support"))
            {
                context.Succeed(requirement);
            }
        }

        return Task.CompletedTask;
    }
}

// Register handlers
builder.Services.AddSingleton<IAuthorizationHandler, MinimumAgeHandler>();
builder.Services.AddSingleton<IAuthorizationHandler, OrderAuthorizationHandler>();

Using Authorization in Controllers

Apply authorization policies to protect endpoints:

[ApiController]
[Route("api/[controller]")]
[Authorize] // Requires authentication for all actions
public class OrdersController : ControllerBase
{
    private readonly IOrderService _orderService;
    private readonly IAuthorizationService _authorizationService;

    public OrdersController(
        IOrderService orderService,
        IAuthorizationService authorizationService)
    {
        _orderService = orderService;
        _authorizationService = authorizationService;
    }

    [HttpGet]
    [Authorize(Policy = "CanViewOrders")]
    public async Task<IActionResult> GetOrders()
    {
        var orders = await _orderService.GetOrdersAsync();
        return Ok(orders);
    }

    [HttpPost]
    [Authorize(Policy = "CanCreateOrders")]
    public async Task<IActionResult> CreateOrder(CreateOrderRequest request)
    {
        var order = await _orderService.CreateOrderAsync(request);
        return CreatedAtAction(nameof(GetOrder), new { id = order.Id }, order);
    }

    [HttpGet("{id}")]
    public async Task<IActionResult> GetOrder(Guid id)
    {
        var order = await _orderService.GetOrderByIdAsync(id);

        if (order == null)
            return NotFound();

        // Resource-based authorization
        var authResult = await _authorizationService.AuthorizeAsync(
            User,
            order,
            "View");

        if (!authResult.Succeeded)
            return Forbid();

        return Ok(order);
    }

    [HttpPut("{id}")]
    public async Task<IActionResult> UpdateOrder(Guid id, UpdateOrderRequest request)
    {
        var order = await _orderService.GetOrderByIdAsync(id);

        if (order == null)
            return NotFound();

        var authResult = await _authorizationService.AuthorizeAsync(
            User,
            order,
            "Edit");

        if (!authResult.Succeeded)
            return Forbid();

        await _orderService.UpdateOrderAsync(id, request);
        return NoContent();
    }

    [HttpDelete("{id}")]
    [Authorize(Roles = "Admin")]
    public async Task<IActionResult> DeleteOrder(Guid id)
    {
        await _orderService.DeleteOrderAsync(id);
        return NoContent();
    }
}

Azure Entra ID (formerly Azure AD) Integration

For enterprise applications, integrate with Azure Entra ID:

builder.Services.AddAuthentication(JwtBearerDefaults.AuthenticationScheme)
    .AddMicrosoftIdentityWebApi(options =>
    {
        builder.Configuration.Bind("AzureAd", options);

        options.Events = new JwtBearerEvents
        {
            OnTokenValidated = async context =>
            {
                // Validate additional claims
                var tenantId = context.Principal?.FindFirst("tid")?.Value;
                var allowedTenants = builder.Configuration
                    .GetSection("AllowedTenants")
                    .Get<List<string>>();

                if (allowedTenants != null &&
                    !allowedTenants.Contains(tenantId))
                {
                    context.Fail("Unauthorized tenant");
                }
            }
        };
    },
    options => builder.Configuration.Bind("AzureAd", options));

// appsettings.json
/*
{
  "AzureAd": {
    "Instance": "https://login.microsoftonline.com/",
    "Domain": "yourdomain.onmicrosoft.com",
    "TenantId": "your-tenant-id",
    "ClientId": "your-client-id",
    "Audience": "api://your-api-id"
  },
  "AllowedTenants": ["tenant-id-1", "tenant-id-2"]
}
*/

Service-to-Service Authentication

Secure communication between microservices using Azure Managed Identity:

// Configure HTTP client with managed identity authentication
builder.Services.AddHttpClient<IOrderServiceClient, OrderServiceClient>(client =>
{
    client.BaseAddress = new Uri(builder.Configuration["Services:OrderService:Url"]!);
    client.DefaultRequestHeaders.Add("User-Agent", "CustomerService/1.0");
    client.Timeout = TimeSpan.FromSeconds(30);
})
.AddHttpMessageHandler<ManagedIdentityHandler>()
.AddPolicyHandler(GetRetryPolicy())
.AddPolicyHandler(GetCircuitBreakerPolicy());

// Managed identity authentication handler
public class ManagedIdentityHandler : DelegatingHandler
{
    private readonly TokenCredential _credential;
    private readonly string _scope;
    private readonly ILogger<ManagedIdentityHandler> _logger;
    private AccessToken? _cachedToken;

    public ManagedIdentityHandler(
        IConfiguration configuration,
        ILogger<ManagedIdentityHandler> logger)
    {
        // DefaultAzureCredential works locally (using Azure CLI, VS, etc.)
        // and in Azure (using Managed Identity)
        _credential = new DefaultAzureCredential(new DefaultAzureCredentialOptions
        {
            ExcludeEnvironmentCredential = false,
            ExcludeWorkloadIdentityCredential = false,
            ExcludeManagedIdentityCredential = false,
            ExcludeSharedTokenCacheCredential = true,
            ExcludeVisualStudioCredential = false,
            ExcludeVisualStudioCodeCredential = false,
            ExcludeAzureCliCredential = false,
            ExcludeAzurePowerShellCredential = true,
            ExcludeInteractiveBrowserCredential = true
        });

        _scope = configuration["Services:OrderService:Scope"]!;
        _logger = logger;
    }

    protected override async Task<HttpResponseMessage> SendAsync(
        HttpRequestMessage request,
        CancellationToken cancellationToken)
    {
        // Check if cached token is still valid
        if (_cachedToken == null ||
            _cachedToken.Value.ExpiresOn <= DateTimeOffset.UtcNow.AddMinutes(5))
        {
            try
            {
                var tokenContext = new TokenRequestContext(new[] { _scope });
                _cachedToken = await _credential.GetTokenAsync(
                    tokenContext,
                    cancellationToken);

                _logger.LogDebug("Successfully acquired access token");
            }
            catch (Exception ex)
            {
                _logger.LogError(ex, "Failed to acquire access token");
                throw;
            }
        }

        request.Headers.Authorization =
            new AuthenticationHeaderValue("Bearer", _cachedToken.Value.Token);

        return await base.SendAsync(request, cancellationToken);
    }
}

// Polly retry policy
static IAsyncPolicy<HttpResponseMessage> GetRetryPolicy()
{
    return HttpPolicyExtensions
        .HandleTransientHttpError()
        .OrResult(msg => msg.StatusCode == System.Net.HttpStatusCode.Unauthorized)
        .WaitAndRetryAsync(3, retryAttempt =>
            TimeSpan.FromSeconds(Math.Pow(2, retryAttempt)));
}

// Circuit breaker policy
static IAsyncPolicy<HttpResponseMessage> GetCircuitBreakerPolicy()
{
    return HttpPolicyExtensions
        .HandleTransientHttpError()
        .CircuitBreakerAsync(5, TimeSpan.FromSeconds(30));
}

API Rate Limiting

Protect your APIs from abuse and ensure fair resource usage with rate limiting (.NET 7+):

using System.Threading.RateLimiting;

builder.Services.AddRateLimiter(options =>
{
    // Global rejection response
    options.OnRejected = async (context, cancellationToken) =>
    {
        context.HttpContext.Response.StatusCode = StatusCodes.Status429TooManyRequests;

        if (context.Lease.TryGetMetadata(MetadataName.RetryAfter, out var retryAfter))
        {
            context.HttpContext.Response.Headers.RetryAfter =
                retryAfter.TotalSeconds.ToString();
        }

        await context.HttpContext.Response.WriteAsJsonAsync(
            new { error = "Too many requests. Please try again later." },
            cancellationToken: cancellationToken);
    };

    // Fixed window limiter
    options.AddFixedWindowLimiter("fixed", options =>
    {
        options.PermitLimit = 100;
        options.Window = TimeSpan.FromMinutes(1);
        options.QueueProcessingOrder = QueueProcessingOrder.OldestFirst;
        options.QueueLimit = 10;
    });

    // Sliding window limiter - more granular than fixed window
    options.AddSlidingWindowLimiter("sliding", options =>
    {
        options.PermitLimit = 100;
        options.Window = TimeSpan.FromMinutes(1);
        options.SegmentsPerWindow = 6; // Divides window into 10-second segments
    });

    // Token bucket - allows bursts while maintaining average rate
    options.AddTokenBucketLimiter("token", options =>
    {
        options.TokenLimit = 100;
        options.ReplenishmentPeriod = TimeSpan.FromMinutes(1);
        options.TokensPerPeriod = 20;
        options.AutoReplenishment = true;
    });

    // Concurrency limiter - limits concurrent requests
    options.AddConcurrencyLimiter("concurrency", options =>
    {
        options.PermitLimit = 50;
        options.QueueProcessingOrder = QueueProcessingOrder.OldestFirst;
        options.QueueLimit = 100;
    });

    // Per-user rate limiting using partition
    options.AddPolicy("per-user", httpContext =>
    {
        var username = httpContext.User.Identity?.Name ?? "anonymous";

        return RateLimitPartition.GetSlidingWindowLimiter(
            partitionKey: username,
            factory: _ => new SlidingWindowRateLimiterOptions
            {
                PermitLimit = 100,
                Window = TimeSpan.FromMinutes(1),
                SegmentsPerWindow = 6
            });
    });

    // Per-IP rate limiting
    options.AddPolicy("per-ip", httpContext =>
    {
        var ipAddress = httpContext.Connection.RemoteIpAddress?.ToString() ?? "unknown";

        return RateLimitPartition.GetTokenBucketLimiter(
            partitionKey: ipAddress,
            factory: _ => new TokenBucketRateLimiterOptions
            {
                TokenLimit = 50,
                ReplenishmentPeriod = TimeSpan.FromMinutes(1),
                TokensPerPeriod = 10,
                AutoReplenishment = true
            });
    });

    // Tiered rate limiting based on user role
    options.AddPolicy("tiered", httpContext =>
    {
        var tier = httpContext.User.IsInRole("Premium") ? "premium" : "free";

        var limits = tier == "premium"
            ? new { PermitLimit = 1000, Window = TimeSpan.FromMinutes(1) }
            : new { PermitLimit = 100, Window = TimeSpan.FromMinutes(1) };

        return RateLimitPartition.GetSlidingWindowLimiter(
            partitionKey: $"{tier}:{httpContext.User.Identity?.Name}",
            factory: _ => new SlidingWindowRateLimiterOptions
            {
                PermitLimit = limits.PermitLimit,
                Window = limits.Window,
                SegmentsPerWindow = 6
            });
    });
});

var app = builder.Build();

// Enable rate limiting middleware (must be before UseAuthorization)
app.UseRateLimiter();

Applying Rate Limiting to Endpoints

[ApiController]
[Route("api/[controller]")]
public class ProductsController : ControllerBase
{
    // Apply named policy
    [EnableRateLimiting("per-user")]
    [HttpGet]
    public async Task<IActionResult> GetProducts()
    {
        // Implementation
        return Ok();
    }

    // Disable rate limiting for specific endpoint
    [DisableRateLimiting]
    [HttpGet("health")]
    public IActionResult Health()
    {
        return Ok(new { status = "healthy" });
    }

    // Apply different policy
    [EnableRateLimiting("token")]
    [HttpPost]
    public async Task<IActionResult> CreateProduct(Product product)
    {
        // Implementation
        return Created();
    }
}

// Apply rate limiting to minimal APIs
app.MapGet("/api/orders", async (IOrderService service) =>
{
    var orders = await service.GetOrdersAsync();
    return Results.Ok(orders);
})
.RequireRateLimiting("per-user");

// Apply globally to all endpoints
app.MapGroup("/api")
    .RequireRateLimiting("sliding");

Secrets Management with Azure Key Vault

Never store secrets in code or configuration files. Use Azure Key Vault:

// Install packages:
// - Azure.Identity
// - Azure.Extensions.AspNetCore.Configuration.Secrets

var keyVaultUrl = builder.Configuration["KeyVault:Url"];

if (!string.IsNullOrEmpty(keyVaultUrl))
{
    builder.Configuration.AddAzureKeyVault(
        new Uri(keyVaultUrl),
        new DefaultAzureCredential());
}

// Access secrets through IConfiguration
public class OrderService
{
    private readonly string _apiKey;
    private readonly string _connectionString;

    public OrderService(IConfiguration configuration)
    {
        // These are loaded from Key Vault
        _apiKey = configuration["PaymentGateway-ApiKey"];
        _connectionString = configuration["Database-ConnectionString"];
    }
}

// For more control, use SecretClient directly
builder.Services.AddSingleton(sp =>
{
    var keyVaultUrl = builder.Configuration["KeyVault:Url"];
    return new SecretClient(
        new Uri(keyVaultUrl),
        new DefaultAzureCredential());
});

public class PaymentService
{
    private readonly SecretClient _secretClient;

    public PaymentService(SecretClient secretClient)
    {
        _secretClient = secretClient;
    }

    public async Task<string> GetApiKeyAsync()
    {
        var secret = await _secretClient.GetSecretAsync("PaymentGateway-ApiKey");
        return secret.Value.Value;
    }
}

Data Protection and Encryption

Encrypt Sensitive Data at Rest

using Microsoft.AspNetCore.DataProtection;

// Configure data protection with Azure Key Vault
builder.Services.AddDataProtection()
    .PersistKeysToAzureBlobStorage(
        new Uri(builder.Configuration["DataProtection:BlobUri"]!),
        new DefaultAzureCredential())
    .ProtectKeysWithAzureKeyVault(
        new Uri(builder.Configuration["DataProtection:KeyVaultKeyUri"]!),
        new DefaultAzureCredential())
    .SetApplicationName("MyApp");

// Use data protection to encrypt sensitive data
public class CustomerService
{
    private readonly IDataProtector _protector;

    public CustomerService(IDataProtectionProvider provider)
    {
        _protector = provider.CreateProtector("CustomerService.v1");
    }

    public string EncryptSensitiveData(string plainText)
    {
        return _protector.Protect(plainText);
    }

    public string DecryptSensitiveData(string cipherText)
    {
        return _protector.Unprotect(cipherText);
    }
}

Always Use HTTPS

// Enforce HTTPS
builder.Services.AddHttpsRedirection(options =>
{
    options.RedirectStatusCode = StatusCodes.Status308PermanentRedirect;
    options.HttpsPort = 443;
});

builder.Services.AddHsts(options =>
{
    options.MaxAge = TimeSpan.FromDays(365);
    options.IncludeSubDomains = true;
    options.Preload = true;
});

var app = builder.Build();

if (!app.Environment.IsDevelopment())
{
    app.UseHsts();
}

app.UseHttpsRedirection();

Security Headers

Add security headers to protect against common attacks:

app.Use(async (context, next) =>
{
    // Prevent clickjacking
    context.Response.Headers.Append("X-Frame-Options", "DENY");

    // Prevent MIME type sniffing
    context.Response.Headers.Append("X-Content-Type-Options", "nosniff");

    // XSS protection
    context.Response.Headers.Append("X-XSS-Protection", "1; mode=block");

    // Content Security Policy
    context.Response.Headers.Append("Content-Security-Policy",
        "default-src 'self'; script-src 'self'; style-src 'self' 'unsafe-inline';");

    // Referrer policy
    context.Response.Headers.Append("Referrer-Policy", "strict-origin-when-cross-origin");

    // Permissions policy
    context.Response.Headers.Append("Permissions-Policy",
        "geolocation=(), microphone=(), camera=()");

    await next();
});

// Or use a middleware package
// Install: NWebsec.AspNetCore.Middleware
app.UseXContentTypeOptions();
app.UseReferrerPolicy(opts => opts.StrictOriginWhenCrossOrigin());
app.UseXXssProtection(opts => opts.EnabledWithBlockMode());
app.UseXfo(opts => opts.Deny());

Input Validation and Sanitization

Always validate and sanitize user input:

public class CreateOrderRequest
{
    [Required]
    [StringLength(100, MinimumLength = 1)]
    public string CustomerName { get; set; } = string.Empty;

    [Required]
    [EmailAddress]
    public string Email { get; set; } = string.Empty;

    [Required]
    [Range(1, int.MaxValue)]
    public decimal Amount { get; set; }

    [Required]
    [MinLength(1)]
    [MaxLength(100)]
    public List<OrderItem> Items { get; set; } = new();
}

// Custom validation
public class CreateOrderRequestValidator : AbstractValidator<CreateOrderRequest>
{
    public CreateOrderRequestValidator()
    {
        RuleFor(x => x.CustomerName)
            .NotEmpty()
            .MaximumLength(100)
            .Matches(@"^[a-zA-Z\s]+$").WithMessage("Name can only contain letters");

        RuleFor(x => x.Email)
            .NotEmpty()
            .EmailAddress();

        RuleFor(x => x.Amount)
            .GreaterThan(0)
            .LessThan(1000000);

        RuleFor(x => x.Items)
            .NotEmpty()
            .Must(items => items.Count <= 100)
            .WithMessage("Cannot exceed 100 items per order");
    }
}

Best Practices Summary

Authentication & Authorization:

• Use Azure Entra ID for enterprise applications
• Implement JWT with short expiration times
• Apply principle of least privilege
• Use resource-based authorization for fine-grained control
• Regularly rotate secrets and credentials

Service-to-Service:

• Use Managed Identity for Azure resources
• Implement certificate-based authentication for non-Azure services
• Never embed credentials in code
• Use Azure Key Vault for all secrets

API Protection:

• Implement rate limiting on all public APIs
• Use different rate limits for different user tiers
• Monitor and alert on rate limit violations
• Consider using Azure API Management for advanced scenarios

Data Security:

• Encrypt sensitive data at rest and in transit
• Use Azure Key Vault for key management
• Implement data protection with key rotation
• Follow GDPR and compliance requirements

General Security:

• Always use HTTPS in production
• Implement proper security headers
• Validate and sanitize all user input
• Log security events for monitoring
• Conduct regular security audits
• Keep dependencies updated
• Use Azure Security Center for threat detection
• Implement proper error handling without exposing sensitive information

Azure-Specific:

• Enable Azure DDoS Protection
• Use Azure Front Door WAF for web application protection
• Implement Azure Monitor and Log Analytics for security monitoring
• Use Azure Private Link for secure service connections
• Enable diagnostic logging on all Azure resources
• Use Azure Policy to enforce security standards
