Best Practices Summary

For REST in .NET:

• Use projection to DTOs (Select instead of .Include() when possible).
• Define endpoint-specific contracts to prevent over-fetch.
• Use AsNoTracking and async LINQ queries for read APIs.

For GraphQL in .NET:

• Use DataLoader pattern to batch N+1 queries.
• Limit query depth & complexity for protection.
• Cache persisted queries when possible.

Over-fetching

• The client receives more data than it needs.
• Example: GET /users/1 returns the entire user entity including addresses, settings, history, but the UI only needs name and email.
• Downsides: unnecessary CPU, bandwidth, and serialization cost.

Under-fetching

• The client receives too little data, requiring multiple round-trips.
• Example: GET /orders/1 returns order header only. The UI then must call /orders/1/items and /orders/1/payments.
• Downsides: chatty APIs, high latency.

2. REST vs GraphQL

2.1) REST APIs

• Pros:

  • Simple, mature, widely supported in .NET (Minimal APIs, ASP.NET Core MVC).
  • Strong HTTP semantics (GET/PUT/POST/DELETE, caching, status codes).
  • Easy to secure with middleware and API gateways.
  • Straightforward to implement with EF Core projections.

• Cons:

  • Fixed shape: risk of over/under-fetching.
  • For complex UI, clients may need multiple calls.

Narrow-down DTOs, Includes, and Projections in REST

• Narrowed-down response models designed for specific endpoints, preventing accidental over-fetch.
• Example: UserProfileDto with only the fields needed for a profile screen.

Includes

• In EF Core, .Include() lets you load related entities in a single query.
• Use carefully: it prevents under-fetching but may over-fetch if you pull deep graphs unnecessarily.

Projections

• Selecting only the needed fields directly from the DB into DTOs.
• Example:

  var users = db.Users
      .Select(u => new UserDto(u.Id, u.Name, u.Email))
      .ToListAsync();

• This is the most efficient pattern for REST endpoints—avoids both over-fetching and under-fetching.

2.2) GraphQL

• Pros:

  • Client defines exactly what fields it wants (solves over/under-fetching elegantly).
  • Single endpoint can serve multiple client needs.
  • Great for frontend-heavy apps (React/Angular/Blazor with many nested queries).

• Cons:

  • Processing cost: server parses & validates dynamic queries → heavier than REST.
  • Memory: query execution may hydrate large graphs before resolving → higher pressure than REST projections.
  • Complexity: harder caching, monitoring, and securing (need query depth limits, persisted queries, etc.).
  • In .NET (HotChocolate, GraphQL.NET): performance is good, but raw REST with EF Core projection is still faster when payload size doesn’t matter.

3. Which is Better in .NET Core

Assuming payload size is irrelevant

• Processing time: REST with EF Core projection is faster because the SQL is pre-shaped and predictable. GraphQL incurs query parsing and field resolution overhead.

• Memory usage: REST wins again; GraphQL’s resolver pipeline often materializes intermediate objects.

• Raw speed (throughput): REST (properly designed DTO + projection) usually achieves higher RPS (requests per second). GraphQL trades some speed for flexibility.

• When GraphQL shines:

  • Complex UI with many optional fields.
  • B2B integrations where clients vary widely in what they need.
  • Cases where reducing network calls is more important than raw speed.

• When REST is better:

  • Internal services and backends where contracts are stable.
  • High-throughput scenarios (10M+ rows, heavy pagination).
  • APIs where performance predictability is critical.

✅ My recommendation

10M+ data, high performance, payload size doesn’t matter

• Stick with REST + EF Core projections + keyset pagination.
• Add GraphQL only if your consumers demand flexible queries across complex object graphs.
