Building a Production-Grade API System with .NET, gRPC, and Microservices Architecture

This article is part of the Comprehensive Guide to Microservices Architecture in .NET Core, Cloud and Azure series.

Source on github licensed under GPL-3.0-or-later

Introduction

This isn't just another CRUD application. We'll build a system that showcases:

Domain-Driven Design (DDD) principles
Command Query Responsibility Segregation (CQRS) pattern
gRPC for high-performance internal communication
Microservices architecture with proper separation of concerns
Full observability with structured logging and distributed tracing
Comprehensive testing strategy across all layers
Multiple deployment options using .NET Aspire and Docker Compose

By the end of this guide, you'll understand not just how to build each component, but why specific architectural decisions matter in production systems.

The Business Requirements

Before diving into architecture, let's understand what we're building. Our Library Management System needs to answer key business questions:

Inventory Insights:

What are the most borrowed books within a specific time range?
Which books are frequently borrowed together?

User Activity:

Who are the most active borrowers in a given period?
What is each user's reading pace (pages per day)?

Circulation Operations:

Allow users to borrow books with proper tracking
Handle book returns with validation

These requirements drive our architectural decisions. We need a system that can efficiently query large datasets (for analytics) while maintaining transactional integrity (for borrowing operations).

Architecture Overview: Why This Design?

The Layered Approach

Our system uses a six-layer architecture, each with a specific responsibility:

1. Domain Layer (src/Library.Domain/) The heart of the application. Contains business entities, value objects, and domain policies. This layer is framework-agnostic and contains the core business logic. By keeping it isolated, we ensure that business rules are testable and independent of infrastructure concerns.

2. Application Layer (src/Library.Application/) Orchestrates the domain layer using the CQRS pattern. Commands handle write operations (borrowing, returning books), while Queries handle read operations (analytics, reporting). This separation allows us to optimize each path independently and provides natural boundaries for caching strategies.

3. Infrastructure Layer (src/Library.Infrastructure/) Implements data persistence using Entity Framework Core and PostgreSQL. This layer depends on the Domain layer but is hidden behind repository interfaces, following the Dependency Inversion Principle. The domain layer never knows about databases, ORMs, or persistence details.

4. Contracts Layer (src/Library.Contracts/) Defines gRPC service contracts using Protocol Buffers. These contracts form the API boundary between internal services, providing strong typing, versioning, and cross-platform compatibility.

5. gRPC Service Layer (src/Library.Grpc/) Implements the gRPC services defined in contracts. This is our "backend" service that owns the business logic and database access. It exposes three main services: Inventory, Circulation, and UserActivity.

6. HTTP API Gateway (src/Library.Api/) Provides a RESTful HTTP interface for external clients. This gateway translates HTTP requests to gRPC calls, handles HTTP-specific concerns (CORS, OpenAPI documentation), and provides a familiar REST interface while leveraging gRPC's performance internally.

Why gRPC Between Layers?

You might wonder: why introduce gRPC between the API Gateway and the business logic service?

Performance: gRPC uses HTTP/2 and Protocol Buffers, offering significant performance improvements over JSON/HTTP REST for internal service communication.

Strong Contracts: Protocol Buffers provide compile-time type safety and automatic client/server code generation.

Microservices Ready: This architecture allows easy horizontal scaling. The API Gateway and gRPC service can be deployed independently, scaled separately based on load, and even deployed across different data centers.

Technology Agnostic: gRPC clients can be generated for any language, making it easy to add services in different tech stacks later.

Step 1: Foundation - The Domain Layer

The Domain layer is where we start because it represents the core business logic, independent of any framework or infrastructure.

Designing Rich Domain Entities

In src/Library.Domain/Entities/, we define three main entities:

Book - Represents books in the library catalog with properties like ISBN, Title, Author, and PageCount. The entity enforces invariants (e.g., PageCount must be positive) directly in its constructor.

User - Represents library members with FullName and RegisteredAt timestamp.

Loan - The most interesting entity, representing a book borrowing transaction. This entity contains business logic such as:

A loan cannot be returned before it was borrowed
A loan cannot be returned twice
The Return method encapsulates the business rules for returning books

These aren't anemic data containers. They're rich objects that protect their invariants and expose behavior through methods, not just property setters.

Value Objects and Domain Policies

In src/Library.Domain/ValueObjects/, we create immutable value objects like ReadingPaceResult and LoanReadingPace. These represent domain concepts that don't have identity but have value through their properties.

The src/Library.Domain/Policies/ReadingPacePolicy.cs class contains the business logic for calculating reading pace. By extracting this into a policy class, we:

Keep the calculation logic testable in isolation
Make it reusable across different contexts
Express business rules explicitly rather than hiding them in entity methods

Repository Interfaces

In src/Library.Domain/Repositories/, we define repository interfaces (IBookRepository, IUserRepository, ILoanRepository). These interfaces are defined in the Domain layer but implemented in the Infrastructure layer. This is the Dependency Inversion Principle in action: high-level domain logic doesn't depend on low-level infrastructure details.

Step 2: Application Layer - CQRS with MediatR

The Application layer (src/Library.Application/) orchestrates domain objects and implements the CQRS pattern.

Understanding CQRS

CQRS separates read operations (Queries) from write operations (Commands). Why?

Different Optimization Strategies: Reads can be cached aggressively, use read replicas, or even use different data stores. Writes need transactional consistency and validation.

Different Models: Queries often need denormalized data for performance, while commands work with normalized domain entities.

Scalability: Read and write workloads can be scaled independently.

Commands for Write Operations

In src/Library.Application/Commands/, we implement:

BorrowBookCommand - Handles the borrowing workflow:

Validate the user exists
Validate the book exists
Create a new Loan entity
Persist via repository
Return the loan ID

ReturnBookCommand - Handles returns:

Retrieve the loan
Call the domain entity's Return method (which enforces business rules)
Persist the change

Each command has a corresponding handler that uses MediatR for request pipeline processing.

Queries for Read Operations

In src/Library.Application/Queries/, we implement:

GetMostBorrowedBooksQuery - Analyzes borrowing patterns to return the most popular books.

GetTopBorrowersQuery - Identifies the most active library users.

GetUserReadingPaceQuery - Calculates how fast a user reads based on loan history.

GetAlsoBorrowedBooksQuery - Finds books that were borrowed by the same users (recommendation engine foundation).

These queries bypass the domain entities and go directly to optimized query services, returning denormalized DTOs perfect for display.

Validation with FluentValidation

In src/Library.Application/Validators/, we create validators for every command and query. FluentValidation provides:

Declarative validation rules
Clear error messages
Easy unit testing
Separation of validation logic from business logic

For example, the BorrowBookCommand validator ensures the user ID and book ID are valid GUIDs, and the borrow date is not in the future.

MediatR Pipeline Behaviors

MediatR allows us to create pipeline behaviors that wrap all commands and queries. We implement:

Validation Behavior - Automatically validates all requests before they reach handlers.

Logging Behavior - Logs all requests and their execution time.

Caching Behavior - Caches query results based on custom cache policies.

This cross-cutting concern approach keeps handlers clean and focused on business logic.

Step 3: Infrastructure Layer - Data Persistence

The Infrastructure layer (src/Library.Infrastructure/) provides concrete implementations of repository interfaces and database access.

DbContext Design

In src/Library.Infrastructure/Data/LibraryDbContext.cs, we configure Entity Framework Core with:

Entity Configuration: Each entity's mapping, constraints, indexes, and relationships are explicitly configured using Fluent API.

UTC DateTime Handling: All DateTime values are automatically converted to UTC to avoid timezone issues.

Change Tracking: Optimized for the workload (tracking enabled for commands, disabled for read-only queries).

Repository Pattern Implementation

In src/Library.Infrastructure/Repositories/, we implement the repository interfaces:

BookRepository - Standard CRUD operations with EF Core.

UserRepository - User management operations.

LoanRepository - Loan operations with navigation property loading.

These repositories encapsulate all EF Core-specific logic, keeping the domain and application layers clean.

Query Service for CQRS Reads

In src/Library.Infrastructure/Queries/QueryService.cs, we implement optimized read operations:

Instead of loading full entity graphs, we project directly to DTOs using EF Core's projection capabilities. This:

Reduces memory allocation
Improves query performance
Allows database-side aggregation

For example, the "most borrowed books" query groups loans by book, counts them, orders by count, and projects to a simple DTO - all executed as a single SQL query.

Database Migrations

Entity Framework migrations track schema changes over time. In src/Library.Infrastructure/Migrations/, we maintain migration history, allowing us to:

Version control our schema
Deploy schema changes alongside application updates
Rollback if needed
Generate the database from scratch in new environments

Step 4: gRPC Contracts - The Service Boundary

In src/Library.Contracts/Protos-v1/, we define our gRPC service contracts using Protocol Buffers (.proto files).

Defining Service Contracts

inventory.proto - Defines InventoryService with methods:

GetMostBorrowedBooks
GetAlsoBorrowedBooks

circulation.proto - Defines CirculationService with methods:

BorrowBook
ReturnBook

user_activity.proto - Defines UserActivityService with methods:

GetTopBorrowers
GetReadingPace

Each service definition includes request/response message types with proper field numbering for versioning.

Why Protocol Buffers?

Efficiency: Binary serialization is faster and smaller than JSON
Type Safety: Strongly typed contracts prevent errors at compile time
Evolution: Field numbers allow backward-compatible changes
Multi-Language: Generate clients in any language
Documentation: The .proto files serve as living documentation

Versioning Strategy

Notice the v1 in the proto file names and namespaces. This allows us to:

Release breaking changes as v2 while maintaining v1
Run multiple API versions simultaneously
Migrate clients gradually
Maintain backward compatibility

Step 5: gRPC Service Implementation

In src/Library.Grpc/Services/, we implement the gRPC services defined in our contracts.

Service Implementation Pattern

Each service follows a consistent pattern:

Dependency Injection: Constructor receives IMediator for CQRS
Request Mapping: Convert gRPC request messages to Commands/Queries
Execution: Send to MediatR pipeline
Response Mapping: Convert results back to gRPC response messages
Error Handling: Catch exceptions and convert to appropriate gRPC status codes

For example, InventoryServiceImpl.cs implements GetMostBorrowedBooks by:

Parsing date parameters from the request
Creating a GetMostBorrowedBooksQuery
Sending it through MediatR
Mapping the results to the gRPC response type

Server Configuration

In src/Library.Grpc/Program.cs, we configure:

gRPC Services: Register all service implementations

Server Reflection: Enables tools like grpcurl to discover services dynamically

Health Checks: Implement gRPC health checking protocol

Dependency Injection: Wire up all layers (Application, Infrastructure, Domain)

Database: Configure DbContext with connection string

Observability: Add Serilog for logging, OpenTelemetry for tracing

Step 6: HTTP API Gateway

The src/Library.Api/ project provides a RESTful HTTP interface that internally calls our gRPC services.

Minimal APIs Design

We use ASP.NET Core Minimal APIs for a lightweight, functional approach. Endpoints are organized by feature:

InventoryEndpoints.cs - Maps HTTP routes to InventoryService gRPC calls CirculationEndpoints.cs - Maps HTTP routes to CirculationService gRPC calls UserActivityEndpoints.cs - Maps HTTP routes to UserActivityService gRPC calls

Each endpoint module:

Defines routes with OpenAPI annotations
Validates HTTP parameters
Calls the appropriate gRPC service
Handles gRPC exceptions and translates to HTTP status codes
Maps responses to HTTP-friendly models

Why Not Call MediatR Directly?

You might ask: why add gRPC between the API and the application layer? Why not call MediatR directly?

Separation of Concerns: The API Gateway should only know about HTTP. The business logic service should only know about business logic.

Independent Scaling: We can scale the public-facing API gateway independently from the business logic service.

Security Boundary: The gRPC service never exposes HTTP, reducing attack surface.

Deployment Flexibility: Services can be deployed to different machines, regions, or even cloud providers.

Technology Freedom: Tomorrow, we could add a GraphQL gateway or a WebSocket service, all talking to the same gRPC backend.

OpenAPI / Swagger Integration

In Program.cs, we configure Swagger to:

Generate OpenAPI specification automatically
Provide interactive API documentation
Include XML documentation comments
Show request/response examples

This gives developers a playground to test the API without writing code.

Step 7: Database Migrations and Seeding

The src/Library.MigrationService/ project handles database initialization separately from the application.

Why a Separate Migration Service?

Separation of Concerns: Migration is a one-time task, not part of the application runtime.

Explicit Control: With .NET Aspire, migrations run before the application starts, ensuring the database is ready.

No Startup Delays: The main application doesn't wait for migrations, improving startup time.

Idempotent: Can be run multiple times safely; EF migrations are idempotent.

Data Seeding

The migration service also seeds sample data, which:

Provides realistic test data for development
Demonstrates the domain model
Enables testing of queries immediately
Shows proper entity creation patterns

The seeder in src/Library.MigrationService/DataSeeder.cs creates books, users, and loans with varied dates to make analytics queries meaningful.

Step 8: Observability - Logging and Tracing

Production systems need visibility. We implement comprehensive observability using industry-standard tools.

Structured Logging with Serilog and Seq

Why Serilog?

Structured logging (not just strings)
Multiple sinks (console, file, Seq, etc.)
Enrichers (add context like request ID, user ID)
High performance

Why Seq?

Centralized log aggregation
Powerful query language
Search across all services
Alerting on log patterns

In src/Library.ServiceDefaults/, we configure Serilog to:

Log to console (for development)
Log to Seq (for centralized viewing)
Include context (service name, timestamp, log level)
Respect minimum log levels per environment

Distributed Tracing with OpenTelemetry and Jaeger

Why OpenTelemetry?

Vendor-neutral standard
Automatic instrumentation for ASP.NET, EF Core, gRPC
Trace context propagation across services
Exporters for any backend

Why Jaeger?

Visualizes request flows across services
Identifies performance bottlenecks
Shows service dependencies
Correlates with logs

When a request flows from the API Gateway to the gRPC Service to the database, OpenTelemetry creates a trace with spans for each operation. Jaeger visualizes this, showing:

Total request duration
Time spent in each service
Database query performance
gRPC call overhead

This makes performance optimization data-driven, not guesswork.

Health Checks

Both services implement health checks:

Liveness: Is the service running?
Readiness: Is the service ready to handle requests (database connected, etc.)?

These endpoints integrate with Kubernetes, Docker health checks, and .NET Aspire monitoring.

Step 9: Testing Strategy

A production system needs comprehensive testing. We implement four types of tests, each serving a specific purpose.

Unit Tests

Domain Unit Tests (tests/Library.UnitTests.Domain/)

Test domain entities in isolation
Verify business rules (e.g., loan cannot be returned twice)
Test domain policies (reading pace calculation)
Fast, no dependencies

Application Unit Tests (tests/Library.UnitTests.Application/)

Test command/query handlers with mocked repositories
Verify validation logic
Test pipeline behaviors
Ensure CQRS handlers work correctly

Integration Tests

Infrastructure Integration Tests (tests/Library.IntegrationTests.Infrastructure/)

Test repositories against a real PostgreSQL database
Verify EF Core mappings
Test complex queries
Use TestContainers to spin up PostgreSQL in Docker

These tests ensure our ORM configuration works correctly and catch issues like:

Missing indexes
Incorrect relationships
Query performance problems

Functional Tests

gRPC Functional Tests (tests/Library.FunctionalTests.Grpc/)

Test gRPC services with a real database
Verify service contracts
Test request/response mapping
Ensure error handling works

These tests use WebApplicationFactory to spin up the gRPC service in-memory and TestContainers for PostgreSQL. They verify that the entire gRPC stack works correctly.

System Tests

API System Tests (tests/Library.SystemTests.Api/)

Test the entire system end-to-end
HTTP requests → API Gateway → gRPC Service → Database
Verify the full user experience
Test error scenarios

These tests ensure all layers integrate correctly and the system behaves as users expect.

Test Organization

Notice the naming pattern: Library.[TestType].[LayerUnderTest]

This makes it clear:

What kind of test it is
What it's testing
Where to add new tests

Step 10: Deployment Options

We provide two deployment strategies, each suited for different scenarios.

.NET Aspire for Development and Local Testing

What is .NET Aspire? .NET Aspire is Microsoft's new cloud-ready stack for building observable, production-ready distributed apps. It provides:

Orchestration (like docker-compose, but .NET-native)
Service discovery
Automatic observability wiring
Dashboard for monitoring
Local development parity with production

The AppHost (apphost/Library.AppHost/Program.cs)

This is the orchestration definition. It:

Defines all services (PostgreSQL, Seq, Jaeger, Migration Service, gRPC Service, API Gateway)
Wires up dependencies (API Gateway depends on gRPC Service)
Configures wait conditions (wait for database before starting services)
Passes configuration (connection strings, endpoints)
Adds observability automatically

Running with Aspire:

Simply run the AppHost project, and .NET Aspire:

Starts PostgreSQL in a container
Starts Seq for logging
Starts Jaeger for tracing
Runs migrations
Starts the gRPC Service
Starts the API Gateway
Opens a dashboard showing all services, logs, and traces

It's development environment as code.

Docker Compose for Production-Like Deployment

Why Docker Compose?

Standard, widely supported
Works in CI/CD pipelines
Closer to production (Kubernetes, cloud services)
No .NET-specific tooling required

The Compose File (deploy/docker-compose.yml)

Defines five services:

postgres - PostgreSQL database with health checks
seq - Log aggregation
jaeger - Distributed tracing
library-grpc - The gRPC backend service
library-api - The HTTP API Gateway

Each service:

Has health checks
Depends on required services
Uses environment variables for configuration
Exposes appropriate ports
Mounts volumes for data persistence

Dockerfiles (deploy/Dockerfile.grpc, deploy/Dockerfile.api)

Multi-stage builds that:

Build Stage: Restore packages, build the project
Publish Stage: Publish optimized release build
Runtime Stage: Copy published files to minimal runtime image

The runtime images:

Use the minimal ASP.NET runtime (not the SDK)
Run as non-root user for security
Include health checks
Set appropriate environment variables

Step 11: Advanced Patterns and Considerations

Caching Strategy

The Application layer includes caching for queries through MediatR behaviors. Queries implement ICacheableQuery to opt into caching with:

Cache key generation
TTL (time to live)
Invalidation strategy

For example, "most borrowed books" is cached for 5 minutes because the data doesn't change frequently, but user-specific reading pace is not cached because it's personalized.

Error Handling

Each layer handles errors appropriately:

Domain Layer: Throws domain-specific exceptions (e.g., InvalidOperationException when trying to return an already-returned loan)

Application Layer: Catches domain exceptions and translates them to application results

gRPC Layer: Catches application exceptions and returns gRPC status codes (InvalidArgument, NotFound, etc.)

API Gateway: Catches gRPC exceptions and returns HTTP status codes (400, 404, 500)

This layered error handling ensures:

Inner layers don't know about outer layer concerns
Errors are translated appropriately at each boundary
Clients receive meaningful error messages

Validation Strategy

We validate at multiple layers, each with a different purpose:

Domain Layer: Enforces business invariants (e.g., PageCount > 0)

Application Layer: Validates commands/queries with FluentValidation (e.g., valid GUIDs, dates)

API Gateway: Validates HTTP-specific concerns (e.g., proper date format, parameter presence)

This defense-in-depth approach catches errors early and provides clear error messages.

Lessons Learned and Best Practices

Start with the Domain

Always start with the Domain layer. If you don't understand the business logic, no amount of fancy architecture will save you. Spend time modeling the domain correctly, and the rest flows naturally.

CQRS Isn't Always Necessary

CQRS adds complexity. Use it when:

Read and write patterns differ significantly
You need different optimization strategies
The business naturally separates commands and queries

For simple CRUD operations, CQRS might be overkill.

gRPC for Internal, REST for Public

gRPC excels for internal service communication but has a learning curve for external clients. The API Gateway pattern gives you the best of both worlds:

gRPC's performance internally
REST's familiarity externally

Observability from Day One

Don't add logging and tracing as an afterthought. Bake it in from the start. When (not if) things go wrong in production, you'll thank yourself for having comprehensive observability.

Test Strategically

Not all code needs the same level of testing:

Domain logic: Unit test heavily
API endpoints: System test the happy paths, unit test error cases
Infrastructure: Integration test key scenarios
Simple DTOs and mappers: Don't bother

Focus testing effort where bugs have the highest impact.

Configuration Management

Use strongly-typed configuration (IOptions pattern). Validate configuration at startup. Fail fast if configuration is wrong. Don't let misconfiguration make it to production.

Database Migrations

Never auto-apply migrations in production. Review them, test them in staging, and apply them as a separate deployment step. Database changes are risky; treat them with respect.

Scaling and Production Considerations

Horizontal Scaling

This architecture supports horizontal scaling:

API Gateway: Stateless, can run multiple instances behind a load balancer
gRPC Service: Stateless, can scale horizontally
PostgreSQL: Can use read replicas for queries, primary for commands

Caching Layer

For high-scale scenarios, add Redis:

Distributed caching across API Gateway instances
Session state (if needed)
Query result caching with shorter TTLs

Message Queue for Async Operations

For operations that don't need immediate consistency, add a message queue (RabbitMQ, Azure Service Bus):

Send email notifications asynchronously
Generate analytics reports in the background
Decouple services further

Database Optimizations

As data grows:

Add indexes on frequently queried columns
Partition large tables (loans table by date)
Archive old data
Use materialized views for complex analytics

Security Considerations

Before production:

Add authentication (JWT, OAuth2)
Add authorization (role-based or policy-based)
Enable HTTPS/TLS everywhere
Implement rate limiting
Add API key validation for service-to-service calls
Scan dependencies for vulnerabilities

Conclusion

Building a production-grade system requires more than just writing code that works. It requires thoughtful architecture, comprehensive testing, observability, and deployment automation.

This Library Management System demonstrates:

Clean Architecture with proper separation of concerns
Domain-Driven Design for rich business logic
CQRS for optimized read and write paths
gRPC for high-performance internal communication
Modern .NET features and best practices
Full observability with logging and tracing
Multiple deployment options for different scenarios
Comprehensive testing at all levels

The key takeaway isn't the specific technologies used (gRPC, PostgreSQL, etc.). It's the architectural principles:

Dependency inversion
Separation of concerns
Explicit boundaries between layers
Testability
Observability
Scalability

These principles apply regardless of your tech stack.

Start with a solid domain model, add clean architecture layers, implement proper observability, test thoroughly, and automate deployment. Do these things, and you'll build systems that are maintainable, scalable, and actually enjoyable to work on.

Next Steps

To explore this implementation in detail:

Clone the repository and examine the project structure in src/ and tests/
Run it locally with .NET Aspire to see the dashboard and observability in action
Explore the code - each file is documented with XML comments explaining the "why"
Run the tests to understand the testing strategy
Deploy with Docker Compose to see the production-like setup
Modify and extend - try adding new features using the existing patterns

The code is open source under GPL-3.0, so feel free to learn from it, fork it, and adapt it to your needs. Just remember: any derivative work must also be open source under GPL-3.0.

Happy coding, and may your services always return 200 OK! 🚀

About the Project

Repository: [Your Repository URL]
License: GNU General Public License v3.0
Author: Hossein Esmati (desmati@gmail.com)
Blog: https://nova-globen.se/blog/

This article is part of a series on building production-grade .NET applications. For more in-depth articles, visit my blog.
