This article is part of the Comprehensive Guide to Microservices Architecture in .NET Core, Cloud and Azure series.
This article explores proven approaches to API versioning in .NET, consumer-driven contract testing with Pact.NET, and best practices for managing deprecation cycles. We'll cover modern techniques for maintaining contract stability in cloud-native applications deployed to Azure.
API Versioning Strategies
Different versioning approaches suit different scenarios. Choose based on your API consumers, organizational standards, and technical constraints.
1. URL Versioning (Recommended)
The most explicit and widely adopted approach, embedding the version directly in the URL path:
// Install package
// dotnet add package Asp.Versioning.Mvc
builder.Services.AddApiVersioning(options =>
{
options.DefaultApiVersion = new ApiVersion(1, 0);
options.AssumeDefaultVersionWhenUnspecified = true;
options.ReportApiVersions = true; // Adds version info to response headers
options.ApiVersionReader = new UrlSegmentApiVersionReader();
})
.AddApiExplorer(options =>
{
options.GroupNameFormat = "'v'VVV"; // Format version as 'v1', 'v2', etc.
options.SubstituteApiVersionInUrl = true;
});
[ApiController]
[Route("api/v{version:apiVersion}/[controller]")]
public class OrdersController : ControllerBase
{
private readonly IOrderService _orderService;
private readonly ILogger<OrdersController> _logger;
public OrdersController(
IOrderService orderService,
ILogger<OrdersController> logger)
{
_orderService = orderService;
_logger = logger;
}
// Version 1.0 - Original implementation
[HttpGet("{id}")]
[MapToApiVersion("1.0")]
public async Task<ActionResult<OrderV1Dto>> GetV1(Guid id)
{
var order = await _orderService.GetOrderByIdAsync(id);
if (order == null)
return NotFound();
return Ok(new OrderV1Dto
{
Id = order.Id,
Total = order.TotalAmount,
Status = order.Status.ToString()
});
}
// Version 2.0 - Enhanced with additional fields
[HttpGet("{id}")]
[MapToApiVersion("2.0")]
public async Task<ActionResult<OrderV2Dto>> GetV2(Guid id)
{
var order = await _orderService.GetOrderByIdAsync(id);
if (order == null)
return NotFound();
return Ok(new OrderV2Dto
{
Id = order.Id,
TotalAmount = order.TotalAmount,
Currency = order.Currency,
Status = order.Status.ToString(),
CustomerInfo = new CustomerInfoDto
{
CustomerId = order.CustomerId,
CustomerName = order.CustomerName
},
CreatedAt = order.CreatedAt,
UpdatedAt = order.UpdatedAt
});
}
// Version 2.0 - New endpoint not available in v1
[HttpPost]
[MapToApiVersion("2.0")]
public async Task<ActionResult<OrderV2Dto>> CreateOrder(CreateOrderRequest request)
{
var order = await _orderService.CreateOrderAsync(request);
return CreatedAtAction(nameof(GetV2),
new { id = order.Id, version = "2.0" },
order);
}
}
// DTOs for different versions
public class OrderV1Dto
{
public Guid Id { get; set; }
public decimal Total { get; set; }
public string Status { get; set; }
}
public class OrderV2Dto
{
public Guid Id { get; set; }
public decimal TotalAmount { get; set; }
public string Currency { get; set; }
public string Status { get; set; }
public CustomerInfoDto CustomerInfo { get; set; }
public DateTime CreatedAt { get; set; }
public DateTime? UpdatedAt { get; set; }
}
public class CustomerInfoDto
{
public Guid CustomerId { get; set; }
public string CustomerName { get; set; }
}
Pros:
- Clear and explicit in URLs and documentation
- Easy to route and cache
- Simple for consumers to understand
- Works well with API gateways
Cons:
- URLs change between versions
- Can lead to code duplication
2. Header Versioning
Version information is passed via HTTP headers, keeping URLs clean:
builder.Services.AddApiVersioning(options =>
{
options.DefaultApiVersion = new ApiVersion(1, 0);
options.AssumeDefaultVersionWhenUnspecified = true;
options.ReportApiVersions = true;
options.ApiVersionReader = new HeaderApiVersionReader("X-API-Version");
});
[ApiController]
[Route("api/[controller]")]
[ApiVersion("1.0")]
[ApiVersion("2.0")]
public class ProductsController : ControllerBase
{
[HttpGet("{id}")]
[MapToApiVersion("1.0")]
public async Task<ActionResult<ProductV1>> GetV1(Guid id)
{
// Implementation
}
[HttpGet("{id}")]
[MapToApiVersion("2.0")]
public async Task<ActionResult<ProductV2>> GetV2(Guid id)
{
// Implementation
}
}
// Client usage:
// GET /api/products/123
// X-API-Version: 2.0
Pros:
- Clean, stable URLs
- Good for RESTful purists
- Easier URL structure
Cons:
- Less discoverable
- Harder to test in browsers
- Caching complications
3. Media Type Versioning (Content Negotiation)
Version is specified in the Accept header using custom media types:
builder.Services.AddApiVersioning(options =>
{
options.DefaultApiVersion = new ApiVersion(1, 0);
options.AssumeDefaultVersionWhenUnspecified = true;
options.ApiVersionReader = new MediaTypeApiVersionReader();
});
[ApiController]
[Route("api/[controller]")]
public class CustomersController : ControllerBase
{
[HttpGet("{id}")]
[MapToApiVersion("1.0")]
[Produces("application/vnd.company.customer.v1+json")]
public async Task<ActionResult<CustomerV1>> GetV1(Guid id)
{
// Implementation
}
[HttpGet("{id}")]
[MapToApiVersion("2.0")]
[Produces("application/vnd.company.customer.v2+json")]
public async Task<ActionResult<CustomerV2>> GetV2(Guid id)
{
// Implementation
}
}
// Client usage:
// GET /api/customers/123
// Accept: application/vnd.company.customer.v2+json
Pros:
- RESTful and follows HTTP standards
- Clean URLs
- Precise control over content negotiation
Cons:
- Most complex to implement
- Harder for consumers to understand
- Limited tooling support
4. Query Parameter Versioning
Version is passed as a query string parameter:
builder.Services.AddApiVersioning(options =>
{
options.DefaultApiVersion = new ApiVersion(1, 0);
options.AssumeDefaultVersionWhenUnspecified = true;
options.ApiVersionReader = new QueryStringApiVersionReader("api-version");
});
[ApiController]
[Route("api/[controller]")]
public class OrdersController : ControllerBase
{
[HttpGet]
[MapToApiVersion("1.0")]
public async Task<ActionResult<IEnumerable<OrderV1>>> GetAllV1()
{
// Implementation
}
[HttpGet]
[MapToApiVersion("2.0")]
public async Task<ActionResult<IEnumerable<OrderV2>>> GetAllV2()
{
// Implementation
}
}
// Client usage:
// GET /api/orders?api-version=2.0
Pros:
- Easy to implement
- Simple for testing
- Optional versioning
Cons:
- Query parameters can be lost or modified
- Not as clean as URL versioning
- Can conflict with other query parameters
Swagger/OpenAPI Integration
Configure Swagger to document multiple API versions:
builder.Services.AddEndpointsApiExplorer();
builder.Services.AddSwaggerGen(options =>
{
options.SwaggerDoc("v1", new OpenApiInfo
{
Version = "v1",
Title = "Orders API v1",
Description = "Original version of the Orders API",
Contact = new OpenApiContact
{
Name = "API Support",
Email = "api-support@company.com"
}
});
options.SwaggerDoc("v2", new OpenApiInfo
{
Version = "v2",
Title = "Orders API v2",
Description = "Enhanced version with additional customer information",
Contact = new OpenApiContact
{
Name = "API Support",
Email = "api-support@company.com"
}
});
// Filter endpoints by version
options.DocInclusionPredicate((docName, apiDesc) =>
{
if (!apiDesc.TryGetMethodInfo(out var methodInfo))
return false;
var versions = methodInfo.DeclaringType?
.GetCustomAttributes(true)
.OfType<ApiVersionAttribute>()
.SelectMany(attr => attr.Versions);
return versions?.Any(v => $"v{v}" == docName) ?? false;
});
});
var app = builder.Build();
app.UseSwagger();
app.UseSwaggerUI(options =>
{
options.SwaggerEndpoint("/swagger/v1/swagger.json", "Orders API V1");
options.SwaggerEndpoint("/swagger/v2/swagger.json", "Orders API V2");
});
Consumer-Driven Contracts (CDC) with Pact.NET
Consumer-Driven Contract testing ensures that provider services meet the expectations defined by their consumers. This prevents breaking changes from reaching production.
Setting Up Pact.NET
# Install Pact.NET packages
dotnet add package PactNet
dotnet add package PactNet.Output.Xunit
Consumer Test (Order Service)
The consumer defines its expectations for the Customer Service API:
using PactNet;
using PactNet.Matchers;
using Xunit;
using Xunit.Abstractions;
namespace OrderService.Tests.Pact
{
public class CustomerServiceConsumerTests : IDisposable
{
private readonly IPactBuilderV4 _pactBuilder;
private readonly ITestOutputHelper _output;
public CustomerServiceConsumerTests(ITestOutputHelper output)
{
_output = output;
var pactConfig = new PactConfig
{
PactDir = Path.Combine("..", "..", "..", "pacts"),
LogLevel = PactLogLevel.Debug,
Outputters = new[] { new XunitOutput(_output) }
};
_pactBuilder = Pact.V4("OrderService", "CustomerService", pactConfig)
.WithHttpInteractions();
}
[Fact]
public async Task GetCustomer_ReturnsCustomerDetails()
{
// Arrange - Define the expected interaction
_pactBuilder
.UponReceiving("A request for customer details")
.Given("Customer 123 exists")
.WithRequest(HttpMethod.Get, "/api/customers/123")
.WithHeader("Accept", "application/json")
.WillRespond()
.WithStatus(HttpStatusCode.OK)
.WithHeader("Content-Type", "application/json")
.WithJsonBody(new
{
id = Match.Type("123"),
name = Match.Type("John Doe"),
email = Match.Regex("john@example.com", "^[\\w-\\.]+@([\\w-]+\\.)+[\\w-]{2,4}$"),
status = Match.Type("Active")
});
await _pactBuilder.VerifyAsync(async ctx =>
{
// Act - Call the consumer code
var httpClient = new HttpClient
{
BaseAddress = ctx.MockServerUri
};
var customerClient = new CustomerServiceClient(httpClient);
var customer = await customerClient.GetCustomerAsync("123");
// Assert - Verify the consumer behaves correctly
Assert.NotNull(customer);
Assert.Equal("123", customer.Id);
Assert.Equal("John Doe", customer.Name);
Assert.Equal("john@example.com", customer.Email);
Assert.Equal("Active", customer.Status);
});
}
[Fact]
public async Task GetCustomer_WhenNotFound_Returns404()
{
// Arrange
_pactBuilder
.UponReceiving("A request for non-existent customer")
.Given("Customer 999 does not exist")
.WithRequest(HttpMethod.Get, "/api/customers/999")
.WithHeader("Accept", "application/json")
.WillRespond()
.WithStatus(HttpStatusCode.NotFound);
await _pactBuilder.VerifyAsync(async ctx =>
{
// Act
var httpClient = new HttpClient
{
BaseAddress = ctx.MockServerUri
};
var customerClient = new CustomerServiceClient(httpClient);
var customer = await customerClient.GetCustomerAsync("999");
// Assert
Assert.Null(customer);
});
}
[Fact]
public async Task CreateCustomer_ReturnsCreatedCustomer()
{
// Arrange
_pactBuilder
.UponReceiving("A request to create a customer")
.Given("No customer with email john@example.com exists")
.WithRequest(HttpMethod.Post, "/api/customers")
.WithHeader("Content-Type", "application/json")
.WithJsonBody(new
{
name = "John Doe",
email = "john@example.com"
})
.WillRespond()
.WithStatus(HttpStatusCode.Created)
.WithHeader("Content-Type", "application/json")
.WithJsonBody(new
{
id = Match.Type("new-id"),
name = Match.Type("John Doe"),
email = Match.Type("john@example.com"),
status = Match.Type("Active")
});
await _pactBuilder.VerifyAsync(async ctx =>
{
// Act
var httpClient = new HttpClient
{
BaseAddress = ctx.MockServerUri
};
var customerClient = new CustomerServiceClient(httpClient);
var customer = await customerClient.CreateCustomerAsync(
new CreateCustomerRequest
{
Name = "John Doe",
Email = "john@example.com"
});
// Assert
Assert.NotNull(customer);
Assert.NotNull(customer.Id);
Assert.Equal("John Doe", customer.Name);
});
}
public void Dispose()
{
_pactBuilder.Dispose();
}
}
}
Provider Test (Customer Service)
The provider verifies it meets the contract defined by consumers:
using Microsoft.AspNetCore.Hosting;
using Microsoft.AspNetCore.TestHost;
using PactNet;
using PactNet.Output.Xunit;
using Xunit;
using Xunit.Abstractions;
namespace CustomerService.Tests.Pact
{
public class CustomerServiceProviderTests
{
private readonly ITestOutputHelper _output;
private readonly string _pactFilePath;
public CustomerServiceProviderTests(ITestOutputHelper output)
{
_output = output;
_pactFilePath = Path.Combine("..", "..", "..", "..",
"OrderService.Tests", "pacts",
"orderservice-customerservice.json");
}
[Fact]
public void EnsureCustomerServiceHonorsContract()
{
// Arrange - Start the provider API
var webHost = new WebHostBuilder()
.UseStartup<Startup>()
.UseUrls("http://localhost:5000")
.Build();
webHost.Start();
try
{
// Act & Assert - Verify the provider against the contract
var config = new PactVerifierConfig
{
Outputters = new[] { new XunitOutput(_output) },
LogLevel = PactLogLevel.Debug
};
new PactVerifier(config)
.ServiceProvider("CustomerService", new Uri("http://localhost:5000"))
.WithFileSource(new FileInfo(_pactFilePath))
.WithProviderStateUrl(new Uri("http://localhost:5000/provider-states"))
.Verify();
}
finally
{
webHost.StopAsync().Wait();
}
}
}
// Provider state controller for test data setup
[ApiController]
[Route("provider-states")]
public class ProviderStatesController : ControllerBase
{
private readonly ICustomerRepository _repository;
public ProviderStatesController(ICustomerRepository repository)
{
_repository = repository;
}
[HttpPost]
public async Task<IActionResult> SetProviderState([FromBody] ProviderState state)
{
switch (state.State)
{
case "Customer 123 exists":
await _repository.SeedTestCustomer(new Customer
{
Id = "123",
Name = "John Doe",
Email = "john@example.com",
Status = "Active"
});
break;
case "Customer 999 does not exist":
await _repository.DeleteCustomerIfExists("999");
break;
case "No customer with email john@example.com exists":
await _repository.DeleteCustomerByEmail("john@example.com");
break;
}
return Ok();
}
}
public class ProviderState
{
public string State { get; set; }
public Dictionary<string, object> Params { get; set; }
}
}
CI/CD Integration with Pact Broker
Use Pact Broker to share contracts between teams:
# Azure DevOps Pipeline
trigger:
- main
pool:
vmImage: 'ubuntu-latest'
steps:
- task: DotNetCoreCLI@2
displayName: 'Run Consumer Tests'
inputs:
command: 'test'
projects: '**/OrderService.Tests.csproj'
- task: Bash@3
displayName: 'Publish Pacts to Broker'
inputs:
targetType: 'inline'
script: |
dotnet tool install --global pact-net-cli
pact-broker publish \
--consumer-app-version $(Build.BuildNumber) \
--broker-base-url $(PactBrokerUrl) \
--broker-token $(PactBrokerToken) \
./pacts
- task: DotNetCoreCLI@2
displayName: 'Run Provider Tests'
inputs:
command: 'test'
projects: '**/CustomerService.Tests.csproj'
Alternatives to Pact
While Pact is popular, other options exist:
OpenAPI/Swagger Schema Validation:
// Validate responses against OpenAPI schema
public class OpenApiValidationTests
{
[Fact]
public async Task GetCustomer_ResponseMatchesSchema()
{
var client = _factory.CreateClient();
var response = await client.GetAsync("/api/customers/123");
var schema = await File.ReadAllTextAsync("openapi.json");
var validator = new OpenApiValidator(schema);
await validator.ValidateResponseAsync(
"/api/customers/{id}",
"get",
response);
}
}
Postman Contract Testing:
- Define contracts in Postman collections
- Run with Newman in CI/CD
- Good for teams already using Postman
Specmatic:
- Specification-first approach
- Generates tests from OpenAPI specs
- Supports multiple languages
Additive Changes and Backward Compatibility
The golden rule: Always add, never remove or change (Postel's Law: "Be conservative in what you send, be liberal in what you accept").
Safe Additive Changes
// V1 - Original
public class OrderDto
{
public Guid Id { get; set; }
public decimal Total { get; set; }
public string Status { get; set; }
}
// V1.1 - Adding optional fields (backward compatible)
public class OrderDto
{
public Guid Id { get; set; }
public decimal Total { get; set; }
public string Status { get; set; }
// New optional fields with defaults
public string Currency { get; set; } = "USD";
public DateTime? CreatedAt { get; set; }
public List<string> Tags { get; set; } = new();
}
// Configure JSON serialization to ignore nulls
builder.Services.AddControllers()
.AddJsonOptions(options =>
{
options.JsonSerializerOptions.DefaultIgnoreCondition =
JsonIgnoreCondition.WhenWritingNull;
options.JsonSerializerOptions.Converters.Add(
new JsonStringEnumConverter());
});
Deprecation Strategy
Mark deprecated fields and provide migration paths:
public class OrderDto
{
public Guid Id { get; set; }
// Old field - deprecated
[Obsolete("Use TotalAmount instead. Will be removed in v3.0 (2026-01-01)")]
[JsonPropertyName("total")]
public decimal Total
{
get => TotalAmount;
set => TotalAmount = value;
}
// New field - recommended
[JsonPropertyName("totalAmount")]
public decimal TotalAmount { get; set; }
public string Status { get; set; }
}
Deprecation Headers
Communicate deprecation to API consumers:
[ApiController]
[Route("api/[controller]")]
public class OrdersController : ControllerBase
{
[HttpGet("{id}")]
[ApiVersion("1.0", Deprecated = true)]
[MapToApiVersion("1.0")]
public async Task<ActionResult<OrderV1Dto>> GetV1(Guid id)
{
// Add deprecation headers
Response.Headers.Append("X-API-Deprecated", "true");
Response.Headers.Append("X-API-Sunset", "2025-12-31");
Response.Headers.Append("X-API-Deprecation-Info",
"https://api.company.com/docs/migration/v1-to-v2");
Response.Headers.Append("X-API-Deprecation-Date", "2025-06-01");
Response.Headers.Append("Link",
"</api/v2/orders/{id}>; rel=\"successor-version\"");
var order = await _orderService.GetOrderByIdAsync(id);
if (order == null)
return NotFound();
return Ok(MapToV1Dto(order));
}
[HttpGet("{id}")]
[ApiVersion("2.0")]
[MapToApiVersion("2.0")]
public async Task<ActionResult<OrderV2Dto>> GetV2(Guid id)
{
var order = await _orderService.GetOrderByIdAsync(id);
if (order == null)
return NotFound();
return Ok(MapToV2Dto(order));
}
}
Deprecation Policy
Establish a clear deprecation policy:
# API Deprecation Policy
1. **Announcement**: Deprecation announced at least 6 months before removal
2. **Documentation**: Migration guides published with deprecation notice
3. **Headers**: All deprecated endpoints return deprecation headers
4. **Monitoring**: Track usage of deprecated endpoints
5. **Communication**: Email notifications to registered API consumers
6. **Support Period**: Deprecated versions supported for 6 months minimum
7. **Removal**: Version removed only after support period expires
## Deprecation Timeline Example:
- 2025-01-15: Announce v1 deprecation
- 2025-01-15 to 2025-07-15: Both v1 and v2 supported
- 2025-06-01: Final reminder emails sent
- 2025-07-15: v1 removed, only v2 supported
Monitoring API Versions
Track version usage to inform deprecation decisions:
public class ApiVersionMetricsMiddleware
{
private readonly RequestDelegate _next;
private readonly ILogger<ApiVersionMetricsMiddleware> _logger;
private readonly TelemetryClient _telemetry;
public ApiVersionMetricsMiddleware(
RequestDelegate next,
ILogger<ApiVersionMetricsMiddleware> logger,
TelemetryClient telemetry)
{
_next = next;
_logger = logger;
_telemetry = telemetry;
}
public async Task InvokeAsync(HttpContext context)
{
var apiVersion = context.GetRequestedApiVersion()?.ToString() ?? "unknown";
var endpoint = context.Request.Path.Value;
// Track metrics
_telemetry.TrackMetric("ApiVersionUsage", 1, new Dictionary<string, string>
{
["Version"] = apiVersion,
["Endpoint"] = endpoint,
["Method"] = context.Request.Method
});
// Add version to response headers for debugging
context.Response.OnStarting(() =>
{
context.Response.Headers.Append("X-API-Version", apiVersion);
return Task.CompletedTask;
});
await _next(context);
}
}
// Register middleware
app.UseMiddleware<ApiVersionMetricsMiddleware>();
Azure API Management Integration
For enterprise scenarios, use Azure API Management for advanced versioning:
// Configure policies in Azure API Management
// Version routing policy
<choose>
<when condition="@(context.Request.Headers.GetValueOrDefault("X-API-Version","1.0") == "2.0")">
<set-backend-service base-url="https://api-v2.company.com" />
</when>
<otherwise>
<set-backend-service base-url="https://api-v1.company.com" />
</otherwise>
</choose>
// Deprecation warning policy
<choose>
<when condition="@(context.Request.Headers.GetValueOrDefault("X-API-Version","1.0") == "1.0")">
<set-header name="X-API-Deprecated" exists-action="override">
<value>true</value>
</set-header>
<set-header name="X-API-Sunset" exists-action="override">
<value>2025-12-31</value>
</set-header>
</when>
</choose>
Best Practices Summary
Versioning Strategy:
- Use URL versioning for clarity and simplicity
- Version from day one, even v1.0
- Never reuse version numbers
- Document all versions in OpenAPI/Swagger
- Use semantic versioning (Major.Minor.Patch)
Contract Testing:
- Implement consumer-driven contracts with Pact
- Run contract tests in CI/CD pipeline
- Use Pact Broker for contract sharing
- Verify providers against all consumer contracts
- Keep contracts in version control
Backward Compatibility:
- Follow Postel's Law: add, never remove
- Provide default values for new fields
- Use optional parameters
- Maintain old field names during transition
- Version DTOs separately from domain models
Deprecation:
- Establish clear deprecation timeline (6+ months)
- Communicate through multiple channels
- Use deprecation headers consistently
- Monitor deprecated endpoint usage
- Provide comprehensive migration guides
- Never surprise consumers with breaking changes
Azure-Specific:
- Use Azure API Management for enterprise versioning
- Implement version routing policies
- Enable analytics for version tracking
- Use Azure Monitor for deprecation metrics
- Leverage Azure DevOps for contract testing in CI/CD
Documentation:
- Document all versions in Swagger UI
- Provide migration guides for each version
- Include examples for all versions
- Maintain changelog with breaking changes
- Link to deprecation information in API responses
